PROJECT LIST    Includes Class 10 + 2 CBSE $ ALL Physics Project

         Get Free Circuit diagram and theory

Sensor Circuits :-

    Item                                                       it uses           Price in Rs



1. Automatic street light with 9V Battery     ( LDR )               150
2. Burglar alarm with 9V battery                 ( LDR )               150
3. Color Detector                                       ( LDR )               250
4. Clap Switch                                            ( MIC )              130
5. Electronic Letter Box  with 9V Battery    ( LDR )              150
6. Electronic Eye with 9V Battery                ( LDR )              140
7. Fire Alarm                                             ( Starter )             090
8. Rain Alarm                                                                        090
9. Heat Sensor                                                                      100
10. Water Level Indicator                                                      090
11. Touch Switch                                                                  090



Musical Circuits :-

1. Musical Bell                                            ( UM66 )            080
2. Four Tone Siren                                    ( UM3561 )         120
3. Harmonium                                            ( NE555 )           130

Remote Control  Circuits :-

1. FM Transmitter                                        ( Radio)            090
2. Remote Control Fan                                 ( IR )                225
3. Radar                                                       ( IR )                300

Power Supply Circuits :-

1. Acid Battery                                                                    100
2. Dynamo                                                                          120
3. Solar Cell                                                                        200




4. Transformer                                                                     100
5. Eliminator  1.5 to 12 Volt                                                 120
6. Half Wave Rectifier                                1 Diode             100
7. Full Wave Rectifier                                 2 diode              100
8. Emergency Light                                                              120
9. High Voltage Indicator                                                     100
10. Ni-cad Battery Charger                                                 100

Digital Circuits :-

1. AND + OR + NOT Gates                                               120
2. NAND Gate                                                                    090
3. Disco Light 6 LED                                                           070
Project circuits deals in Hobby circuits for student, low cost circuits for experiment work, Free theory, circuit diagram, tutorial, simple electronics project, complete physics project as listed above, project material etc.

4. Display Board                                                                  190
5. Decimal to Binary Encoder                                               130
6. Digital Volt Meter                                                            130
7. Electronic Dice                                                                 080




8. Head and Tail (Toss)                                                        070
9. Object Counter                                                                180

Misc :-

1. Electroplating Silver                                                         200
2. Intercom                                                                          230
3. Mat Heater                                                                      050
4. Motor                                                                             090
5. Timer                                                                              100
6. Telescope                                                                       120
7. Using Fuse Tube                                                             050
